Electric Hospital Bed DHC-III (DM06) Multifunctional Electric Hospital Bed

Item Specifications
Bed Dimensions (excluding guardrails): (1940×900) ± 10mm
Bed Dimensions (including guardrails): (2275×1070) ± 10mm
Bed Height (excluding cushion): Minimum: (530±20)mm
Bed Height (excluding cushion): Maximum: (730±20)mm
Lifting Stroke (200±20mm) (Electric)
Head-to-Foot Tilt: Head Down: 12°±2° (Electric)
Head-to-Foot Tilt: Foot Down: 15°±2° (Electric)
Back Lift Angle: 65°±5° (Electric)
Leg Lift Angle: 35°±5° (Electric)

Advanced welding technology ensures high-quality welds and a sturdy bed frame capable of carrying a load of 240 kg or more. Equipped with three-stage, center-controlled casters with a high-stability linkage system and a double-wheel design for increased ground contact and stable braking. The head and footboards are blow-molded from high-quality materials in a single operation. The hanging design allows for easy removal, and the footboard features a full touchscreen interface.

The control panel displays all functions and displays angle, weight, and other information. Driven by a medical-grade ultra-quiet DC motor, the unit offers stable and reliable performance, enabling cardiac chair positions, shock positions, CPR positions, and examination positions.

The European-style four-rail design utilizes a damper mechanism to control speed and noise. When lowered, it can be concealed beneath the bed panel, flush with the bed frame.

The rails feature a high-precision load cell and an LCD display for real-time patient weight monitoring.

The control panel on the siderails facilitates operation for both the doctor and the patient. IV pole sockets and drainage hooks are located at each corner, and an optional IV pole is available.
