TH103-4

Advantage:
Compared to the previous generation:
1. Upgraded 800w motor, maximum speed 25-10km
2, both before and after the upgrade of the disc brake, while the rear wheel increased the oil brake, to maximize the safety of the brake, suitable for Yunguichuan mountain road more areas, strongly recommend more mountainous areas to buy this.
3. Upgraded wider and thicker leather seat than the first generation, easy to clean,more grade
4. Upgraded the front 14 inch and back 16 inch super wheel, which has
stronger obstacle crossing ability and can easily get over the sidewalk steps.
5. Upgraded the middle integrated pedal, more durable, can be lifted from the front, more convenient
Parameter
Product size(L*W*H):126*65.5*125cm
Package size (L*W*H):115*65*64cm (plus 125*70*68 rear seat) Motor specification: 48V800W middle differential motor (Max.60V1000W)
Standard battery:48V20AH lead-acid battery
Weight: The naked car weighs 80kg, and the total weight with the standard battery is 105kg
Range:25-100km (depending on the battery, 48V20AH lead-acid battery is standard)
Front wheel specification: 14 inch vacuum tire Rear wheel specification: 16 inch vacuum tire Other size parameters (unit cm):
Seat cushion [Width: 46| depth:45|ground height: 55] Seat back [Width:45|Height:57]
Seat headrest [Width:27.5|Height:20]
Seat armrest [Inner width:43| outer width:59]
